Meraki Star Metals Oil & Gas Equipment Trading L.L.C. Meraki has more undeniable standing and appreciation among the general undertakings and today it is widely supervised as Manufacturers, Suppliers, and Exporters. Very Duplex Steel Zeron 100 Pipes that we are offering have more essential appreciation among the general undertakings and are tracked down utilized in various undertakings for different purposes. Besides, it has changed into an optimal decision for key current applications because of different remarkable properties tracked down in it. We are making and giving the lines to the purchaser at different nuances that are moving in types, wall thickness, points, outside assessment, plans, length, and so on. Moreover, it is preposterously given to the purchasers at slice constructed nuances as per the request the purchasers are having as need might arise. We are in this way guaranteeing in impetus the giving of the lines to the purchasers and looking awesome.
Zeron 100 Pipes & Tubes Manufacturers, Zeron 100 Pipes & Tubes Suppliers, Zeron 100 Pipes & Tubes Stcokists, Zeron 100 Pipes & Tubes Exporters
Zeron 100 Pipes & Tubes Manufacturers in UAE, Zeron 100 Pipes & Tubes Suppliers in UAE, Zeron 100 Pipes & Tubes Stcokists in UAE, Zeron 100 Pipes & Tubes Exporters in UAE
Zeron 100 is the very duplex treated steel blend that is having magnificent deterioration safe cutoff nearby more critical strength. It usually contains nickel of 7 %, chromium of 25 %, and molybdenum of 3.6 % notwithstanding other alloying parts like tungsten and copper. This composite has a 50-50 austenitic-ferritic structure. The composite is additionally having safe capacity to opening use, chloride pitting and stress deterioration breaking as well. This blend UNS task is S32760. Zeron 100 is, with the expansion of alloying parts in right quality like molybdenum, chromium, and tungsten, having ordinarily heavenly pitting impervious to several ordinary acids and chloride acids. ZETON 100 is made for meeting the pitting deterioration safe undefined in any occasion of 40. The increase of composite parts like nitrogen and being ferritic structure fortifies high yielding that is two times that of treated steel of 300. Zeron 100 is similarly having copper alloying parts likewise that are giving dumbfounding sulfuric horrendous safe and subsequently, the blend is utilized in the damaging channel mining applications and any overabundance associations that are experiencing sulfuric disastrous.
Zeron 100 Pipes & Tubes Manufacturers in Dubai, Zeron 100 Pipes & Tubes Suppliers in Dubai, Zeron 100 Pipes & Tubes Stcokists in Dubai, Zeron 100 Pipes & Tubes Exporters in Dubai
Pipe Specification :ASTM A790, A358 / ASME SA790, SA358
Dimension Standard :ANSI B36.19M, ANSI B36.10
Outside Diameter :6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock
Thickness Range :0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type :Seamless / ERW / Welded / Fabricated Pipes
Form :Round, Square, Rectangular, Oval, Hydraulic Etc
Length :Single Random, Double Random & Required Length
End :Plain End, Beveled End, Treaded
End Protection :Plastic Caps
Outside Finish :2B, No.4, No.1, No.8 Mirror Finish for Super Duplex Steel Pipes, Finish as per customer Requirements
Delivery Condition :Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Inspection, Test Reports :Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing :Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials :Sizes and Specifications other than above can be manufactured on request
Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
Zeron 100 | 109 | 80 | 25 | 28 HRC |
Tensile Strength, ksi | 90 min |
---|---|
0.2% Yield Strength, ksi | 65 min |
Elongation, % | 25 min |
Hardness [HRC] | 293 max |
Density lbm/in3 | Electrical Resistivity mW•in | Thermal Conductivity (BTU/hr•ft•°F) | Heat Capacity BTU/lbm•°F | Electrical Resistivity (in x 10-6) | |
---|---|---|---|---|---|
at 68°F | 0.278 | 27.6 | 8.7 | 0.112 | 33.5 |
at 212°F | 26.1 | 9.2 | 0.119 | 35.4 | |
at 392°F | 25.4 | 9.8 | 0.127 | 37.4 | |
at 572°F | 24.9 | 10.4 | 0.134 | 39.4 |
