Meraki Star Metals Oil & Gas Equipment Trading L.L.C. an essential stockiest and exporter of the whole current steel and SS 347/347H Pipes and Tubes. Our everything is made with the best and mind boggling of the ordinary substance and overall principles. Our everything is generally speaking around endeavored and examined before the development to the clients and transporters. We even produce the changed kind of the things according to the client points and direction in addition.
SS 347/347H Pipes and Tubes are made with the different sorts of the detail like adaptability, end, condition, types, structures, shape, size, thickness, length, width, rules, viewpoints, grade, finish, surface, and applications as well. These lines are even organized with the assistance of several substance mixes like carbon, nickel, manganese, chromium, sulfur, silicon, cobalt, titanium, and phosphorus. These lines and chambers are organized with both physical and mechanical properties like unyielding nature, yield strength, expanding, thickness, hardness, crazy adaptability, warm conductivity, and electrical conductivity, modulus of headway, electrical resistivity, and proof pressure in addition. These lines are open in different sorts and plans like made, consistent, ERW, EFW, and LSAW.
Stainless Steel 347/347H Pipes & Tubes Manufacturers, Stainless Steel 347/347H Pipes & Tubes Suppliers, Stainless Steel 347/347H Pipes & Tubes Stcokists, Stainless Steel 347/347H Pipes & Tubes Exporters
Stainless Steel 347/347H Pipes & Tubes Manufacturers in UAE, Stainless Steel 347/347H Pipes & Tubes Suppliers in UAE, Stainless Steel 347/347H Pipes & Tubes Stcokists in UAE, Stainless Steel 347/347H Pipes & Tubes Exporters in UAE
SS 347/347H Pipes and Tubes is legitimate for the utilization in endless the applications, for example, gas dealing with, petrochemicals industry, power age industry, heat exchanger drugs hardware, drug industry, seawater gear, designed gear, specialty compound industry, condensers, paper industry, around the sea oil debilitating industry, and squash industry too. These lines are moreover reasonable in a piece of the general works like military applications, plane parts, shafts, siphons, food industry, home machines, rails, cranes, transportation, and vehicle parts too.
SS 347/347H Pipes and Tubes are made with the warming and welding treatment for better execution in the solidified temperatures and conditions. These pies are explicitly organized with layered accuracy for use in the substance business and food industry also. These chambers are safeguarded from the whole far reaching usage like pitting crumbling, influence deterioration, stress crumbling, split breaking down, and seawater rust. These lines and chambers need to go through a piece of the tests like the colossal degree test, minuscule test, compound test, hardness test, mechanical test, hydrostatic test, radiography test, transmitting test, fixing test, PMI test, and ultrasonic test too.
Stainless Steel 347/347H Pipes & Tubes Manufacturers in Dubai, Stainless Steel 347/347H Pipes & Tubes Suppliers in Dubai, Stainless Steel 347/347H Pipes & Tubes Stcokists in Dubai, Stainless Steel 347/347H Pipes & Tubes Exporters in Dubai
STANDARD | UNS | WNR. | EN | JIS | GOST |
---|---|---|---|---|---|
SS 347 | S34700 | 1.4550 | X6CrNiNb18-10 | SUS 347 | 08Ch18N12B |
SS 347H | S34709 | 1.4961 | X6CrNiNb18-12 | SUS 347H | - |
Stainless Steel Pipe Specification : ASTM A312, A358 / ASME SA312, SA358
SS Tube Specification : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Pipe Size : 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes.
Tube Size : 1/2" OD to 8" OD.
Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Outside Finish : 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request
Element | C | Cr | Mn | Ni | P | S | Si | Cb/Ta |
---|---|---|---|---|---|---|---|---|
347 | 0.08 max |
min: 17.0 max: 20.0 |
2.0 max |
min: 9.0 max: 13.0 |
0.04 max |
0.30 max |
0.75 max |
min:10x C max: 1.0 |
347H |
min: 0.04 max: 0.10 |
min: 17.0 max: 20.0 |
2.0 max | min: 9.0 max: 13.0 |
0.03 max | 0.30 max |
0.75 max |
min:10x C max: 1.0 |
Grade | Tensile Strength ksi (MPa) min | Yield Strength 0.2% ksi offset ksi (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell) MAX | Hardness (Rockwell B) MAX |
---|---|---|---|---|---|
347/347H |
75 (515) |
30 (205) |
40 | 201 | 95 |
Density lbm/in3 |
Coefficient of Thermal Expansion (min/in)-°F |
Thermal Conductivity BTU/hr-ft-°F | Specific Heat BTU/lbm -°F | Modules of Elasticity (annealed)2-psi | |
---|---|---|---|---|---|
at 68 °F | at 68 – 212°F | at 68 – 1832°F | 68-932°F | at 32 – 212°F | in tension (E) |
0.288 | 9.2 | 11.4 | 14.7 | 0.12 | 28 x 106 |
