Exclusive distributor & stockist of Flanges, Pipe Fittings, Buttweld Fittings, Forged Fittings & Pipes & Tubes, Sheets & Plates, Round Bars, Fasteners in UAE

We Meraki Star Metals Oil & Gas Equipment Trading L.L.C. has a spot with conceivably the clearest Creators, Stockists, and Suppliers of the colossal number of metal works. We have been offering such help beginning with one side of the planet and then onto the following. Our product range is thorough of SS 316/316L/316Ti Sheets and Plates. This thing is among the most referred to grade of Steel into grouping portions of social event affiliations. This thing is containing the unmistakable extent of nickel parts that give pervasive disintegrating fixing qualities.

Likewise, they are tracked down in the fields of marine applications by the uprightness of its reasonable climatic flexibility and protecting credits. This thing is good to go with the different customizations stressed over its shapes, sizes, viewpoints, thickness, etc. It is the last call decision of our clients. In any case, they all are created utilizing from one side of the planet to the next saw standards. The controlling speculation behind these sets of steel is covered under the ASTM A240 and ASME SA240. They are equivalently sensible for both the appearances, for instance hot rolled and cold moved metals.

Stainless Steel 316 / 316L / 316Ti Sheets And Plates Manufacturers, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Suppliers, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Stcokists, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Exporters

Stainless Steel 316 / 316L / 316Ti Sheets And Plates Manufacturers in UAE, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Suppliers in UAE, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Stcokists in UAE, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Exporters in UAE

SS 304/304L/304H Sheets and Plates are very used by the paper and squash experiences, material gear producer, condensers in oil based product and atomic fuel age stations, and petrochemical dealing with stuff makers. The hypothesis behind the nuances of these grade sheets and plates is tended to by the ASTM A240 and ASME SA240 rules.

SS 316/316L/316Ti Sheets and Plates have the best advancing point at 1399 degrees Celsius (or 2550 degrees Fahrenheit). They show wonderful pliability as well as yield strength ranges. It has the most raised level of prolongation at 35%. Since it has a spot with the 300 families; as such they correspondingly have the planned make-up of carbon, manganese, silicon, phosphorus, sulfur, chromium, molybdenum, nitrogen, and nickel.

They are the more consistently found in the constructional as well as game plan works. For the clarification that it is truly open and financially savvy in nature; it is being used in party kitchenettes like BBQ grills. They are moreover uncommonly referred to in making the vessels, tanks, and limit compartments in the substance managing endeavors. As they incorporate uncommon tension alongside strain deterrent credits. Additionally, they have been utilized by the material equipment, paper, and crush gear, food managing stuff encounters, etc.

SS 316/316L/316Ti Sheets and Plates are moreover present forward for the tests like PMI test, sending off test, evening out test, IGC test, etc. Other than this, they give documentations like power treatment chart, material detectable quality endorsements, QAP, raw substance confirmations, fumigation tests, etc.

Stainless Steel 316 / 316L / 316Ti Sheets And Plates Manufacturers in Dubai, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Suppliers in Dubai, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Stcokists in Dubai, Stainless Steel 316 / 316L / 316Ti Sheets And Plates Exporters in Dubai

316/316L/316Ti Stainless Steel Sheets and Plates Equivalent Grades

STANDARD UNS WNR. AFNOR EN JIS BS GOST
SS 316 S31600 1.4401 / 1.4436 Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3 SUS 316 316S31 / 316S33 -
SS 316L S31603 1.4404 / 1.4435 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2
SS 316Ti S31635 1.4571 Z2 NCDU 25-20 X1NiCrMoCu25-20-5 SUS 316Ti 904S13 -

Stainless Steel Sheets and Plates Specification : ASTM A240 / ASME SA240
Dimension Standard : JIS, AISI, ASTM, GB, DIN, EN, etc
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing : Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.

C Mn Si P S Cr Mo Ni N
316
(S31600)
0.08
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316L
(S31603)
0.03
max
2.0
max
0.75
max
0.045
max
0.03
max
min: 16.0
max: 18.0
min: 2.0
max: 3.0
min: 10.0
max: 14.0
0.10
max
316TI(S31635) - - - - - 16.0 2.00 10.0 -
0.08 2 0.75 0.045 0.03 18.0 3.00 14.0 0.1

Grade Tensile Strength
ksi (min)
Yield Strength
0.2% ksi (min)
Elongation % Hardness (Brinell) MAX Hardness
(Rockwell B) MAX
316
(S31600)
75 30 40 217 95
316L
(S31603)
70 25 40 217 95
316TI(S31635) 515(Mpa) 205(Mpa) 35 205 75

SS 316/316L
Density
lbm/in3
Thermal Conductivity
(BTU/h ft. °F)
Electrical
Resistivity
(in x 10-6)
Modulus of
Elasticity
(psi x 106
Coefficient of
Thermal Expansion
(in/in)/
°F x 10-6
Specific Heat
(BTU/lb/
°F)
Melting
Range
(°F)
at 68°F: 0.285 9.4 at 212°F 28.3 at 68°F 28 9.4 at 32 – 212°F 0.1200 at 68°F to 212°F 2500 to 2590
12.4 at 932 °F 39.4 at 752°F 10.2 at 32 – 1000°F
49.6 at 1652 °F 10.4 at 32 – 1500°F
SS 316Ti
Denstiy
lbm/in3
Coefficient of
Thermal Expansion (min/in)-°F
Thermal Conductivity BTU/hr-ft-°F Specific Heat BTU/lbm -°F Modules of Elasticity (annealed)2-psi
at 68 °F at 68 – 212°F at 68 – 1600°F at 212°F at 932°F at 32 – 212°F in tension (E)
0.285 9.2 11.0 9.4 12.4 0.12 29 x 106
