Meraki Star Metals Oil & Gas Equipment Trading L.L.C. is a highly acclaimed manufacturer and supplier of all ferrous and non-ferrous pipe products. Our company has carved an unparalleled position in the industry by making persistent efforts to cater to customers with premium quality industrial piping products. Nickel 201 Pipes are manufactured by us that are highly in demand because of its prominent features. We stock and supply these pipes under the strict norms of global standards. The offered products are available in different sizes, specifications, standards, and designations. In our technically sound infrastructure and availability of trending machines we are able to fabricate products with full precision and surface finish. We also offer these pipes with machining allowances and surface finish. Our experienced and efficient technical personnel maintain the quality standards of products right from using qualified materials for finished products.
Nickel N02201 Seamless Pipes are dual certified grade pipes having wrought nickel. These pipes only differentiate by the carbon composition. These pipes are a solid solution for industrial commercial pure applications. The alloying restriction combined into one grade having dual certified chemistry that result in a change in desired mechanical properties. The application of nickel pipes includes chemical processing in the most severe chemicals such as acetic acids, nitric acids, phosphoric acids, and other harsh chemical environments. These pipes can be exposed to other organic and inorganic compound environments. Nickel 201 grade has outstanding resistance to moderate alkalis in a variety of temperatures and concentrations.
These pipes offer great service in the operating temperatures up to 600 deg F, thus carbon composition raised to higher. In addition to the lower carbon content, it becomes resistive to graphitization. These pipes can be subjected to embrittlement. We construct these pipes according to the international standards and pressure design codes.
Nickel 201 Sheets & Plates Manufacturers, Nickel 201 Sheets & Plates Suppliers, Nickel 201 Sheets & Plates Stcokists, Nickel 201 Sheets & Plates Exporters
Nickel 201 Sheets & Plates Manufacturers in UAE, Nickel 201 Sheets & Plates Suppliers in UAE, Nickel 201 Sheets & Plates Stcokists in UAE, Nickel 201 Sheets & Plates Exporters in UAE
Nickel 201 Sheets & Plates Manufacturers in Dubai, Nickel 201 Sheets & Plates Suppliers in Dubai, Nickel 201 Sheets & Plates Stcokists in Dubai, Nickel 201 Sheets & Plates Exporters in Dubai
Specifications | ASTM B162 / ASME SB162 |
Dimension Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
Thickness | 0.3 mm to 120 mm |
Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. | Surface Finishing | Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc. |
Grade | C | Mn | Si | S | Cu | Fe | Ni |
Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
