Meraki Star Metals Oil & Gas Equipment Trading L.L.C. put forward a lot of measures of energy to devise pragmatically extraordinary things that are usable in different circumstances. We make these things using top of the line raw parts and subsequently ensure their faithful quality and strength. Our Tantalum Sheets are hard, malleable and incredibly disintegration-safe. These Tantalum Sheets are impenetrable to a ton of various fabricated material. Our sheets delivered utilizing Tantalum have a high condensing point and can be formed into exceptionally small protective oxide layers on first-class capacitors. Our Tantalum Sheets are used in various organizations, for instance, research office supplies, super-blend added substances in nickel-composites, substitutes for platinum and that is just a glimpse of something larger. These Tantalum Sheets are used in applications where threatening or damaging properties are required. Also, these sheets track down use in substances dealing with and military applications.

Tantalum Sheet & Plate Manufacturers, Tantalum Sheet & Plate Suppliers, Tantalum Sheet & Plate Stcokists, Tantalum Sheet & Plate Exporters

Tantalum Sheet & Plate Manufacturers in UAE, Tantalum Sheet & Plate Suppliers in UAE, Tantalum Sheet & Plate Stcokists in UAE, Tantalum Sheet & Plate Exporters in UAE

Tantalum Sheet & Plate Manufacturers in Dubai, Tantalum Sheet & Plate Suppliers in Dubai, Tantalum Sheet & Plate Stcokists in Dubai, Tantalum Sheet & Plate Exporters in Dubai

Purity :99.95％min or 99.99％min conformity with ASTM B 708 98

Size:

	Width (mm)	Length (mm)	Thickness (mm)
Foil	0.03-0.07	30-200	>50
Sheet	0.07-0.5	30- 700	30-2000
Board	0.5-10	50-1000	50-3000
Purity	>=99.95％ or 99.99％

Element	R05200 (%,Max)	R05400 (%,Max)
C	0.01	0.01
O	0.015	0.03
N	0.01	0.01
H	0.0015	0.0015
Fe	0.01	0.01
Mo	0.02	0.02
Nb	0.1	0.1
Ni	0.01	0.01
Si	0.005	0.005
Ti	0.01	0.01
W	0.05	0.05

Grade and size	Annealed
Grade and size	Tensile strength min， psi (MPa)	Yield strength min，psi (MPa)(2％)	Elongation min，％ (1 inch gage length)
Sheet， foil. and board (RO5200， RO5400)　Thickness<0.060"(1.524mm) Thickness≥0.060"(1.524mm)	30000 (207)	20000 (138)	20
	25000 (172)	15000 (103)	30
Ta-10W　(RO5255) Sheet， foil. and board	70000 (482)	60000 (414)	15
Ta-10W　(RO5255) Sheet， foil. and board	70000 (482)	55000 (379)	20
Ta-2.5W(RO5252) Thickness<0.125" (3.175mm) Thickness≥0.125" (3.175mm)	40000 (276)	30000 (207)	20
	40000 (276)	22000　(152)	25
Ta-40Nb　(RO5240) Thickness<0.060"(1.524mm)	40000 (276)	20000 (138)	25
Thickness>0.060"(1.524mm)	35000 (241)	15000 (103)	25
